Case Dimensions

• Height: 349mm (13.7 inches)
• Width: 210mm (8.3 inches)
• Depth: 372mm (14.6 inches)
• Weight: 5.9 kg (13 lb)

Component Clearance

• CPU Cooler: Maximum height of 165mm
• Graphics Card:
  • Maximum length between 265mm and 325mm (depending on case configuration)
  • Maximum thickness of 44mm
• Front Radiator: Maximum depth of 85mm for fans and radiator combined

Front Panel

• 1 x USB 3.2 Gen 2 Type-A port
• 1 x USB 3.2 Gen 1 Type-C port
• 1 x Headset audio jack

Fan and RGB Control

• 3 fan channels, each with a maximum power output of 10W
• 2 NZXT RGB connectors supporting up to 40 LEDs

Expansion Slots

• 2 standard expansion slots (no vertical slots)

Drive Bays

• 3 + 1 x 2.5" drive bays
• 1 x 3.5" drive bay

Cooling

• Fan Support:
  • Front: 2 x 120mm or 2 x 140mm fans
  • Top: 1 x 120mm fan
  • Rear: 1 x 120mm fan
• All air intakes have filters
• Radiator Support:
  • Front: Up to 240mm radiator
  • Top: Not compatible with radiators
  • Rear: Up to 120mm radiator

Pre-installed Fans (for reference only)

• Model: Aer P 120mm
• Speed: 1200 ± 200 RPM
• Airflow: 50.42 CFM
• Noise Level: 28 dBA
• Connector: 3-pin
